Waterproof 32pins Screw Heavy Duty Connector

MOQ: 5pcs/30pcs/50pcs
Price: $8/$7.5/$7
Delivery Period: 5~7 work days
Payment Method: T/T
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
ZJHK
Certification
UL,COC,CE,UKCA,SGS,EAC,RoHS
Model Number
HE-032-M/HE-032-F
Document
HE-016-F（17-32）.pdf
Pollution Degree:
3
Productname:
Heavy Duty Rectangular Connector
Operatingtemperaturerange:
-40°C To +125°C
Reated Voltage:
500V
Current:
16A
Contact Type:
Screw
Number Of Contacts:
32
Protection:
IP65
Housings:
H32B
Highlight:

waterproof heavy duty connector

,

32pin screw connector

,

rectangular waterproof connector

Product Description
Waterproof 32pins Screw Heavy Duty Connector
Waterproof 32-pin heavy duty connector front view
Waterproof 32-pin heavy duty connector side view
The HE-032-M/F standard connector is designed for 32B size hoods and housings. Constructed with two 16-pin inserts, these connectors feature screw terminals that enable easy installation without specialized tools, making them ideal for straightforward working environments.
Product Specifications
ParameterSpecification
Termination methodScrew terminal
GenderMale/Female
Number of contacts32
ModelHE-032-M/HE-032-F
Rated Current16A
Rated Voltage500V
Rated Impulse Voltage6kV
Pollution DegreeⅢ
Rated Voltage Acc.to UL Csa600V
Insulation Resistance≥10¹⁰Ω
MaterialPolycarbonate
Flammability Acc.to UL94V0
Mechanical Working Life-mating Cycles≥500
ContactsCopper Alloy
Contact Resistance≤1mΩ
Wire Gauge0.14-2.5mm²
AWG26-14
Product Technical Drawings
HE-016-M(17~32)
HE-016-M connector technical drawing
HE-016-F(17~32)
HE-016-F connector technical drawing
Product Series Expansion
HE series heavy duty connector product line
The HE series represents one of our core product lines. We also manufacture multiple connector series including HA, HQ, and HM to address diverse application requirements across various industries. Our comprehensive offering extends to complementary products such as hoods, housings, cable glands, and specialized tools. Contact us for consultation and ordering.
Professional Facilities and Warehouse
Skyray Instrument manufacturing facility
ZJHK warehouse and inventory management
SKYRAY INSTRUMENT: Skyray Instrument is a recognized leader in the heavy-duty connector industry, delivering high-performance, reliable connectivity solutions for challenging applications including industrial automation, rail transit, and energy equipment. Through advanced engineering and strict quality control, our products perform reliably even under extreme conditions, enhancing system safety, operational efficiency, and long-term durability.
WAREHOUSE: Our vertically integrated business model combines extensive warehouse facilities with in-house manufacturing capabilities for heavy-duty connectors. By maintaining comprehensive component inventories and leveraging deep production expertise, we efficiently deliver both standard and fully customized connector designs. This synergy ensures reliable, responsive supply chain management and rapid adaptation to client requirements.
Certifications
RoHS certification
RoHS
UL certification
UL
EAC certification
EAC
SGS certification
SGS
CE certification
CE
Company Profile
ZJHK company overview and facilities
ZJHK Heavy-Duty Connectors are recognized for their reliability and robust performance in demanding environments. With a proven track record in communication equipment, these connectors integrate power and data solutions, ensuring stable connections even in harsh conditions. Committed to continuous improvement, ZJHK is increasing investment in R&D to enhance product technology and optimize performance. Our connectors are designed to meet the evolving needs of industries like BESS, 5G, and data centers, providing high-end, reliable interconnection solutions for complex systems.
